High Definition LCD Monitor


  • HDTV

Contents start

The OEV262H is a 26" LCD monitor which is able to display full HD images and has been designed specifically for use with Olympus endoscopy systems. It has a range of display modes including PIP and POP, to allow the optimal display of images, and multiple input terminals, ensuring compatibility with a wide range of image sources.

  • Add to Watch List
  • Brochure

Full HD imaging designed specifically for Olympus endoscopes

26-inch Full HD LCD panel with a 16:9 aspect ratio, high brightness, high contrast, and high gradation images.

FLIP Function for suitable display pattern and monitor layout

FLIP functions (such as mirror and 180° rotation) which provide suitable display pattern and monitor layout for the procedure.

Various display modes to match clinical needs

Multi-modality display capability, including Picture in Picture (PIP), Picture out Picture (POP), and Clone Out*1 with various image size combinations.

Multiple input terminals for a range of video signals

Various input/output terminals, including 3G/HD/SD SDI (x2), DVI-I (x2), HD15, Y/C, and VIDEO.

Eco-friendly specification

Eco-friendly specifications by low power consumption, various power saving mode, lightweight and thin body compared to the predecessor*2.

A.I.M.E (Advanced Image Multiple Enhancer)

A.I.M.E (Advanced Image Multiple Enhancer)*3 which supports to enhance the image quality of the OLYMPUS endoscopy system.

*1 Clone Out is the function that outputs the HD video signal (1080i/1080p) as displayed including PIP/POP image to the second monitor and recording device.
*3 A.I.M.E. (Advanced Image Multiple Enhancer) is the function that improves the resolution with saving the noise gain up.

LCD panel Screen size 26 inches
Display devices a-Si TFT active matrix
Resolution 1920x1080 dots (Full HD)
Contrast ratio 1400:1
Aspect ratio 16:9
Viewing angle 178° (Horizontal & Vertical)
Number of colors 1.07 billion
Size Dimensions 626.8 (W) x 395.2 (H) x 79.6 (D) mm
Weight 7.8 kg
Power Supply LCD monitor AC IN : 100-240 V, 50/60 Hz, 0.96-0.47 A
DC IN : 24 V, 3.6 A, 5 V, 0.03 A
(supplied by optional AC adapter)
Input HD/SD SDI (1) BNC connector
SDI (2)
VIDEO BNC connector
Y/C 4-pin mini-DIN
HD15 D-sub 15-pin
DVI (1) DVI-I connector
DVI (2) DVI-I connector
Aux in (HD/SD-SDI) BNC connector
Output HD/SD SDI (1) BNC connector With active - Through output and auto 75 Ω termination
SDI (2)
VIDEO BNC connector With loop-through output and auto 75 Ω termination
Y/C 4-pin mini-DIN With active-through output
HD15 D-sub 15-pin With active-through output
DVI (1) DVI-I connector With active-through output
DVI (2)
Clone Out (3G/HD-SDI) BNC connector
Remote RS-232Cconnector D-sub 9-pin
Parallel remote RJ-45

Optional HD15-BNC4P cable "SONY SMF-405" is required to achieve the connection with RGB signal between OEV262H and CV-260/CV-260SL.
For more information, please contact your OLYMPUS.
