The Olympus ENF-VT2 rhino-laryngo videoscope offers users outstanding observation capacity and treatment performance. Its high-quality imaging, clear vision and close focus for higher accuracy allow for high-resolution office therapy for transnasal laryngoscopy- /vocal cord- and pharynx procedures.

The Olympus ENF-VT2 rhino-laryngo videoscope offers users outstanding observation capacity and treatment performance. Its high-quality imaging delivers some of the clearest, brightest images in a videoscope; the suction mechanism allows a clear view; the close focus feature permits close observation up to 2mm and therefore more details due to magnified images; and the chip-on-the-tip concept eliminates typical fiberscope wear-out. Together, these features allow for high-resolution office therapy for transnasal laryngoscopy- / vocal cord- / pharynx procedures.

  • Add to Watch List
  • Brochure

High quality imaging

Delivering some of the brightest, clearest images in a videoendoscope, ENF-VT2 is facilitating a detailed image - even in smaller vessels - for easier diagnosis.

Clear vision

The suction mechanism allows users to keep a clear view, with easy push-button switching during treatments.

Improved diagnosis

Narrow Band Imaging (NBI) in combination with NBI compatible video systems and ENF-VT2’s close focus function allow recognition of smallest lesions and detailed observation of mucosa for early detection.

Ergonomic handling

Programmable remote buttons allow direct access to selectable functions during the observation.

Durability

The chip-on-the-tip concept excludes optical fibres, thereby eliminating the typical wear-out effect of broken fibres in flexible fiberscopes with offering same compatibilities to cleaning and disinfection methods known from fiberscopes.

Exceptional image quality

The chip-on-the-tip CCD videochip provides a sharp, bright and crisp image quality, far superior to that of flexible fiberscopes.

2mm close focus feature for image magnification

The close-focus feature allows close observation of the tissue as near as 2mm, enabling detailed views during observation of the mucosa, e.g. for taking very precise biopsies.

NBI compatibility for early lesion detection

Observation with Narrow Band Imaging (NBI) - in NBI compatible video systems - allows users to recognise small lesions in an early stage and, therefore, helps in early cancer detection.

Flexible range of accessories

20 different types of accessories are available, giving users a wide range of instruments to choose from to facilitate the procedure.

Optical System Field of view 90°
Direction of view
Depth of field 2 - 40 mm
Insertion Tube Distal end outer diameter 4.8 mm
Flexible tube outer diameter 4.9 mm
Working length 265 mm
Instrument Channel Channel inner diameter 2 mm
Minimum visible distance 3 mm
Bending Section Angulation range Up 130°, Down 130°
Total Length   635 mm
NBI   Available
Optera Video Processor with Built-in LED Light Source CV-170

Optera Video Processor with Built-in LED Light Source

CV-170

  • HDTV
  • NBI
  • LED
  • HDTV image quality and NBI
  • Long-life LED light source
  • Pre-freeze function
  • Brochure
VISERA ELITE Video Processor OTV-S190

VISERA ELITE Video Processor

OTV-S190

  • HDTV
  • NBI
  • Ground- breaking resolving power for safe procedure
  • Brighter, more powerful NBI
  • Outstanding, true-to-life image quality
  • Brochure
Video Processor OTV-SI

Video Processor

OTV-SI

  • Space-Saving design
  • Unprecedented image quality
  • Contour Enhancement
  • Brochure
VISERA ELITE Xenon Light Source CLV-S190

VISERA ELITE Xenon Light Source

CLV-S190

  • NBI
  • Brighter, more powerful Narrow Band Imaging
  • Photo Dynamic Diagnosis
  • Brochure
VISERA  Xenon Light Source CLV-S45

VISERA Xenon Light Source

CLV-S45

  • Powerful Illumination and Long Service Life
  • automatic Brightness Control
  • Turn-Off Function
  • Brochure
LED Light Source CLL-V1

LED Light Source

CLL-V1

  • Powerful Illumination
  • Efficient and eco-friendly
  • Brochure
Halogen Light Source CLH-250

Halogen Light Source

CLH-250

  • Powerful Illumination
  • Simplified Design
  • Excellent Cost-Effectiveness
  • Brochure
Halogen Light Source CLH-SC

Halogen Light Source

CLH-SC

  • Powerful Illumination
  • Space-Efficient, Compact Design
  • Excellent Cost-Effectiveness
  • Brochure
StorobeLED Litght Source CLL-S1

StorobeLED Litght Source

CLL-S1

  • Noise-free
  • Adjustable duty cycle
  • Reliable stroboscopic algorithm
  • Brochure
